Como implementar a criptografia no nível do campo do lado do cliente (CSFLE) em Java com o Spring Data MongoDB

1
git clone git@github.com:mongodb-developer/mongodb-java-spring-boot-csfle.git

1
/**
2
 * This class initialize the Key Vault (collection + keyAltNames unique index) using a dedicated standard connection
3
 * to MongoDB.
4
 * Then it creates the Data Encryption Keys (DEKs) required to encrypt the documents in each of the
5
 * encrypted collections.
6
 */
7
@Component
8
public class KeyVaultAndDekSetup {
9
10
    private static final Logger LOGGER = LoggerFactory.getLogger(KeyVaultAndDekSetup.class);
11
    private final KeyVaultService keyVaultService;
12
    private final DataEncryptionKeyService dataEncryptionKeyService;
13
    @Value("${spring.data.mongodb.vault.uri}")
14
    private String CONNECTION_STR;
15
16
    public KeyVaultAndDekSetup(KeyVaultService keyVaultService, DataEncryptionKeyService dataEncryptionKeyService) {
17
        this.keyVaultService = keyVaultService;
18
        this.dataEncryptionKeyService = dataEncryptionKeyService;
19
    }
20
21
    @PostConstruct
22
    public void postConstruct() {
23
        LOGGER.info("=> Start Encryption Setup.");
24
        LOGGER.debug("=> MongoDB Connection String: {}", CONNECTION_STR);
25
        MongoClientSettings mcs = MongoClientSettings.builder()
26
                                                     .applyConnectionString(new ConnectionString(CONNECTION_STR))
27
                                                     .build();
28
        try (MongoClient client = MongoClients.create(mcs)) {
29
            LOGGER.info("=> Created the MongoClient instance for the encryption setup.");
30
            LOGGER.info("=> Creating the encryption key vault collection.");
31
            keyVaultService.setupKeyVaultCollection(client);
32
            LOGGER.info("=> Creating the Data Encryption Keys.");
33
            EncryptedCollectionsConfiguration.encryptedEntities.forEach(dataEncryptionKeyService::createOrRetrieveDEK);
34
            LOGGER.info("=> Encryption Setup completed.");
35
        } catch (Exception e) {
36
            LOGGER.error("=> Encryption Setup failed: {}", e.getMessage(), e);
37
        }
38
39
    }
40
41
}

1
/**
2
 * Initialization of the Key Vault collection and keyAltNames unique index.
3
 */
4
@Service
5
public class KeyVaultServiceImpl implements KeyVaultService {
6
7
    private static final Logger LOGGER = LoggerFactory.getLogger(KeyVaultServiceImpl.class);
8
    private static final String INDEX_NAME = "uniqueKeyAltNames";
9
    @Value("${mongodb.key.vault.db}")
10
    private String KEY_VAULT_DB;
11
    @Value("${mongodb.key.vault.coll}")
12
    private String KEY_VAULT_COLL;
13
14
    public void setupKeyVaultCollection(MongoClient mongoClient) {
15
        LOGGER.info("=> Setup the key vault collection {}.{}", KEY_VAULT_DB, KEY_VAULT_COLL);
16
        MongoDatabase db = mongoClient.getDatabase(KEY_VAULT_DB);
17
        MongoCollection<Document> vault = db.getCollection(KEY_VAULT_COLL);
18
        boolean vaultExists = doesCollectionExist(db, KEY_VAULT_COLL);
19
        if (vaultExists) {
20
            LOGGER.info("=> Vault collection already exists.");
21
            if (!doesIndexExist(vault)) {
22
                LOGGER.info("=> Unique index created on the keyAltNames");
23
                createKeyVaultIndex(vault);
24
            }
25
        } else {
26
            LOGGER.info("=> Creating a new vault collection & index on keyAltNames.");
27
            createKeyVaultIndex(vault);
28
        }
29
    }
30
31
    private void createKeyVaultIndex(MongoCollection<Document> vault) {
32
        Bson keyAltNamesExists = exists("keyAltNames");
33
        IndexOptions indexOpts = new IndexOptions().name(INDEX_NAME)
34
                                                   .partialFilterExpression(keyAltNamesExists)
35
                                                   .unique(true);
36
        vault.createIndex(new BsonDocument("keyAltNames", new BsonInt32(1)), indexOpts);
37
    }
38
39
    private boolean doesCollectionExist(MongoDatabase db, String coll) {
40
        return db.listCollectionNames().into(new ArrayList<>()).stream().anyMatch(c -> c.equals(coll));
41
    }
42
43
    private boolean doesIndexExist(MongoCollection<Document> coll) {
44
        return coll.listIndexes()
45
                   .into(new ArrayList<>())
46
                   .stream()
47
                   .map(i -> i.get("name"))
48
                   .anyMatch(n -> n.equals(INDEX_NAME));
49
    }
50
}

1
/**
2
 * ClientEncryption used by the DataEncryptionKeyService to create the DEKs.
3
 */
4
@Configuration
5
public class MongoDBKeyVaultClientConfiguration {
6
7
    private static final Logger LOGGER = LoggerFactory.getLogger(MongoDBKeyVaultClientConfiguration.class);
8
    private final KmsService kmsService;
9
    @Value("${spring.data.mongodb.vault.uri}")
10
    private String CONNECTION_STR;
11
    @Value("${mongodb.key.vault.db}")
12
    private String KEY_VAULT_DB;
13
    @Value("${mongodb.key.vault.coll}")
14
    private String KEY_VAULT_COLL;
15
    private MongoNamespace KEY_VAULT_NS;
16
17
    public MongoDBKeyVaultClientConfiguration(KmsService kmsService) {
18
        this.kmsService = kmsService;
19
    }
20
21
    @PostConstruct
22
    public void postConstructor() {
23
        this.KEY_VAULT_NS = new MongoNamespace(KEY_VAULT_DB, KEY_VAULT_COLL);
24
    }
25
26
    /**
27
     * MongoDB Encryption Client that can manage Data Encryption Keys (DEKs).
28
     *
29
     * @return ClientEncryption MongoDB connection that can create or delete DEKs.
30
     */
31
    @Bean
32
    public ClientEncryption clientEncryption() {
33
        LOGGER.info("=> Creating the MongoDB Key Vault Client.");
34
        MongoClientSettings mcs = MongoClientSettings.builder()
35
                                                     .applyConnectionString(new ConnectionString(CONNECTION_STR))
36
                                                     .build();
37
        ClientEncryptionSettings ces = ClientEncryptionSettings.builder()
38
                                                               .keyVaultMongoClientSettings(mcs)
39
                                                               .keyVaultNamespace(KEY_VAULT_NS.getFullName())
40
                                                               .kmsProviders(kmsService.getKmsProviders())
41
                                                               .build();
42
        return ClientEncryptions.create(ces);
43
    }
44
}

1
/**
2
 * Service responsible for creating and remembering the Data Encryption Keys (DEKs).
3
 * We need to retrieve the DEKs when we evaluate the SpEL expressions in the Entities to create the JSON Schemas.
4
 */
5
@Service
6
public class DataEncryptionKeyServiceImpl implements DataEncryptionKeyService {
7
8
    private static final Logger LOGGER = LoggerFactory.getLogger(DataEncryptionKeyServiceImpl.class);
9
    private final ClientEncryption clientEncryption;
10
    private final Map<String, String> dataEncryptionKeysB64 = new HashMap<>();
11
    @Value("${mongodb.kms.provider}")
12
    private String KMS_PROVIDER;
13
14
    public DataEncryptionKeyServiceImpl(ClientEncryption clientEncryption) {
15
        this.clientEncryption = clientEncryption;
16
    }
17
18
    public Map<String, String> getDataEncryptionKeysB64() {
19
        LOGGER.info("=> Getting Data Encryption Keys Base64 Map.");
20
        LOGGER.info("=> Keys in DEK Map: {}", dataEncryptionKeysB64.entrySet());
21
        return dataEncryptionKeysB64;
22
    }
23
24
    public String createOrRetrieveDEK(EncryptedEntity encryptedEntity) {
25
        Base64.Encoder b64Encoder = Base64.getEncoder();
26
        String dekName = encryptedEntity.getDekName();
27
        BsonDocument dek = clientEncryption.getKeyByAltName(dekName);
28
        BsonBinary dataKeyId;
29
        if (dek == null) {
30
            LOGGER.info("=> Creating Data Encryption Key: {}", dekName);
31
            DataKeyOptions dko = new DataKeyOptions().keyAltNames(of(dekName));
32
            dataKeyId = clientEncryption.createDataKey(KMS_PROVIDER, dko);
33
            LOGGER.debug("=> DEK ID: {}", dataKeyId);
34
        } else {
35
            LOGGER.info("=> Existing Data Encryption Key: {}", dekName);
36
            dataKeyId = dek.get("_id").asBinary();
37
            LOGGER.debug("=> DEK ID: {}", dataKeyId);
38
        }
39
        String dek64 = b64Encoder.encodeToString(dataKeyId.getData());
40
        LOGGER.debug("=> Base64 DEK ID: {}", dek64);
41
        LOGGER.info("=> Adding Data Encryption Key to the Map with key: {}",
42
                    encryptedEntity.getEntityClass().getSimpleName());
43
        dataEncryptionKeysB64.put(encryptedEntity.getEntityClass().getSimpleName(), dek64);
44
        return dek64;
45
    }
46
47
}

1
/**
2
 * This is the entity class for the "persons" collection.
3
 * The SpEL expression of the @Encrypted annotation is used to determine the DEK's keyId to use for the encryption.
4
 *
5
 * @see com.mongodb.quickstart.javaspringbootcsfle.components.EntitySpelEvaluationExtension
6
 */
7
@Document("persons")
8
@Encrypted(keyId = "#{mongocrypt.keyId(#target)}")
9
public class PersonEntity {
10
    @Id
11
    private ObjectId id;
12
    private String firstName;
13
    private String lastName;
14
    @Encrypted(algorithm = "AEAD_AES_256_CBC_HMAC_SHA_512-Deterministic")
15
    private String ssn;
16
    @Encrypted(algorithm = "AEAD_AES_256_CBC_HMAC_SHA_512-Random")
17
    private String bloodType;
18
19
    // Constructors
20
21
    @Override
22
    // toString()
23
24
    // Getters & Setters
25
}

1
{
2
  "encryptMetadata": {
3
    "keyId": [
4
      {
5
        "$binary": {
6
          "base64": "WyHXZ+53SSqCC/6WdCvp0w==",
7
          "subType": "04"
8
        }
9
      }
10
    ]
11
  },
12
  "type": "object",
13
  "properties": {
14
    "ssn": {
15
      "encrypt": {
16
        "bsonType": "string",
17
        "algorithm": "AEAD_AES_256_CBC_HMAC_SHA_512-Deterministic"
18
      }
19
    },
20
    "bloodType": {
21
      "encrypt": {
22
        "bsonType": "string",
23
        "algorithm": "AEAD_AES_256_CBC_HMAC_SHA_512-Random"
24
      }
25
    }
26
  }
27
}

1
/**
2
 * Will evaluate the SePL expressions in the Entity classes like this: #{mongocrypt.keyId(#target)} and insert
3
 * the right encryption key for the right collection.
4
 */
5
@Component
6
public class EntitySpelEvaluationExtension implements EvaluationContextExtension {
7
8
    private static final Logger LOGGER = LoggerFactory.getLogger(EntitySpelEvaluationExtension.class);
9
    private final DataEncryptionKeyService dataEncryptionKeyService;
10
11
    public EntitySpelEvaluationExtension(DataEncryptionKeyService dataEncryptionKeyService) {
12
        this.dataEncryptionKeyService = dataEncryptionKeyService;
13
    }
14
15
    @Override
16
    @NonNull
17
    public String getExtensionId() {
18
        return "mongocrypt";
19
    }
20
21
    @Override
22
    @NonNull
23
    public Map<String, Function> getFunctions() {
24
        try {
25
            return Collections.singletonMap("keyId", new Function(
26
                    EntitySpelEvaluationExtension.class.getMethod("computeKeyId", String.class), this));
27
        } catch (NoSuchMethodException e) {
28
            throw new RuntimeException(e);
29
        }
30
    }
31
32
    public String computeKeyId(String target) {
33
        String dek = dataEncryptionKeyService.getDataEncryptionKeysB64().get(target);
34
        LOGGER.info("=> Computing dek for target {} => {}", target, dek);
35
        return dek;
36
    }
37
}

1
/**
2
 * Spring Data MongoDB Configuration for the encrypted MongoClient with all the required configuration (jsonSchemas).
3
 * The big trick in this file is the creation of the JSON Schemas before the creation of the entire configuration as
4
 * we need the MappingContext to resolve the SpEL expressions in the entities.
5
 *
6
 * @see com.mongodb.quickstart.javaspringbootcsfle.components.EntitySpelEvaluationExtension
7
 */
8
@Configuration
9
@DependsOn("keyVaultAndDekSetup")
10
public class MongoDBSecureClientConfiguration {
11
12
    private static final Logger LOGGER = LoggerFactory.getLogger(MongoDBSecureClientConfiguration.class);
13
    private final KmsService kmsService;
14
    private final SchemaService schemaService;
15
    @Value("${crypt.shared.lib.path}")
16
    private String CRYPT_SHARED_LIB_PATH;
17
    @Value("${spring.data.mongodb.storage.uri}")
18
    private String CONNECTION_STR_DATA;
19
    @Value("${spring.data.mongodb.vault.uri}")
20
    private String CONNECTION_STR_VAULT;
21
    @Value("${mongodb.key.vault.db}")
22
    private String KEY_VAULT_DB;
23
    @Value("${mongodb.key.vault.coll}")
24
    private String KEY_VAULT_COLL;
25
    private MongoNamespace KEY_VAULT_NS;
26
27
    public MongoDBSecureClientConfiguration(KmsService kmsService, SchemaService schemaService) {
28
        this.kmsService = kmsService;
29
        this.schemaService = schemaService;
30
    }
31
32
    @PostConstruct
33
    public void postConstruct() {
34
        this.KEY_VAULT_NS = new MongoNamespace(KEY_VAULT_DB, KEY_VAULT_COLL);
35
    }
36
37
    @Bean
38
    public MongoClientSettings mongoClientSettings() {
39
        LOGGER.info("=> Creating the MongoClientSettings for the encrypted collections.");
40
        return MongoClientSettings.builder().applyConnectionString(new ConnectionString(CONNECTION_STR_DATA)).build();
41
    }
42
43
    @Bean
44
    public MongoClientSettingsBuilderCustomizer customizer(MappingContext mappingContext) {
45
        LOGGER.info("=> Creating the MongoClientSettingsBuilderCustomizer.");
46
        return builder -> {
47
            MongoJsonSchemaCreator schemaCreator = MongoJsonSchemaCreator.create(mappingContext);
48
            Map<String, BsonDocument> schemaMap = schemaService.generateSchemasMap(schemaCreator)
49
                                                               .entrySet()
50
                                                               .stream()
51
                                                               .collect(toMap(e -> e.getKey().getFullName(),
52
                                                                              Map.Entry::getValue));
53
            Map<String, Object> extraOptions = Map.of("cryptSharedLibPath", CRYPT_SHARED_LIB_PATH,
54
                                                      "cryptSharedLibRequired", true);
55
            MongoClientSettings mcs = MongoClientSettings.builder()
56
                                                         .applyConnectionString(
57
                                                                 new ConnectionString(CONNECTION_STR_VAULT))
58
                                                         .build();
59
            AutoEncryptionSettings oes = AutoEncryptionSettings.builder()
60
                                                               .keyVaultMongoClientSettings(mcs)
61
                                                               .keyVaultNamespace(KEY_VAULT_NS.getFullName())
62
                                                               .kmsProviders(kmsService.getKmsProviders())
63
                                                               .schemaMap(schemaMap)
64
                                                               .extraOptions(extraOptions)
65
                                                               .build();
66
            builder.autoEncryptionSettings(oes);
67
        };
68
    }
69
}

1
@Service
2
public class SchemaServiceImpl implements SchemaService {
3
4
    private static final Logger LOGGER = LoggerFactory.getLogger(SchemaServiceImpl.class);
5
    private Map<MongoNamespace, BsonDocument> schemasMap;
6
7
    @Override
8
    public Map<MongoNamespace, BsonDocument> generateSchemasMap(MongoJsonSchemaCreator schemaCreator) {
9
        LOGGER.info("=> Generating schema map.");
10
        List<EncryptedEntity> encryptedEntities = EncryptedCollectionsConfiguration.encryptedEntities;
11
        return schemasMap = encryptedEntities.stream()
12
                                             .collect(toMap(EncryptedEntity::getNamespace,
13
                                                            e -> generateSchema(schemaCreator, e.getEntityClass())));
14
    }
15
16
    @Override
17
    public Map<MongoNamespace, BsonDocument> getSchemasMap() {
18
        return schemasMap;
19
    }
20
21
    private BsonDocument generateSchema(MongoJsonSchemaCreator schemaCreator, Class<?> entityClass) {
22
        BsonDocument schema = schemaCreator.filter(MongoJsonSchemaCreator.encryptedOnly())
23
                                           .createSchemaFor(entityClass)
24
                                           .schemaDocument()
25
                                           .toBsonDocument();
26
        LOGGER.info("=> JSON Schema for {}:\n{}", entityClass.getSimpleName(),
27
                    schema.toJson(JsonWriterSettings.builder().indent(true).build()));
28
        return schema;
29
    }
30
31
}

1
/**
2
 * Create or update the encrypted collections with a server side JSON Schema to secure the encrypted field in the MongoDB database.
3
 * This prevents any other client from inserting or editing the fields without encrypting the fields correctly.
4
 */
5
@Component
6
public class EncryptedCollectionsSetup {
7
8
    private static final Logger LOGGER = LoggerFactory.getLogger(EncryptedCollectionsSetup.class);
9
    private final MongoClient mongoClient;
10
    private final SchemaService schemaService;
11
12
    public EncryptedCollectionsSetup(MongoClient mongoClient, SchemaService schemaService) {
13
        this.mongoClient = mongoClient;
14
        this.schemaService = schemaService;
15
    }
16
17
    @PostConstruct
18
    public void postConstruct() {
19
        LOGGER.info("=> Setup the encrypted collections.");
20
        schemaService.getSchemasMap()
21
                     .forEach((namespace, schema) -> createOrUpdateCollection(mongoClient, namespace, schema));
22
    }
23
24
    private void createOrUpdateCollection(MongoClient mongoClient, MongoNamespace ns, BsonDocument schema) {
25
        MongoDatabase db = mongoClient.getDatabase(ns.getDatabaseName());
26
        String collStr = ns.getCollectionName();
27
        if (doesCollectionExist(db, ns)) {
28
            LOGGER.info("=> Updating {} collection's server side JSON Schema.", ns.getFullName());
29
            db.runCommand(new Document("collMod", collStr).append("validator", jsonSchemaWrapper(schema)));
30
        } else {
31
            LOGGER.info("=> Creating encrypted collection {} with server side JSON Schema.", ns.getFullName());
32
            db.createCollection(collStr, new CreateCollectionOptions().validationOptions(
33
                    new ValidationOptions().validator(jsonSchemaWrapper(schema))));
34
        }
35
    }
36
37
    public BsonDocument jsonSchemaWrapper(BsonDocument schema) {
38
        return new BsonDocument("$jsonSchema", schema);
39
    }
40
41
    private boolean doesCollectionExist(MongoDatabase db, MongoNamespace ns) {
42
        return db.listCollectionNames()
43
                 .into(new ArrayList<>())
44
                 .stream()
45
                 .anyMatch(c -> c.equals(ns.getCollectionName()));
46
    }
47
48
}

1
/**
2
 * Information about the encrypted collections in the application.
3
 * As I need the information in multiple places, I decided to create a configuration class with a static list of
4
 * the encrypted collections and their information.
5
 */
6
public class EncryptedCollectionsConfiguration {
7
    public static final List<EncryptedEntity> encryptedEntities = List.of(
8
            new EncryptedEntity("mydb", "persons", PersonEntity.class, "personDEK"),
9
            new EncryptedEntity("mydb", "companies", CompanyEntity.class, "companyDEK"));
10
}

1
/**
2
 * Spring Data MongoDB repository for the PersonEntity
3
 */
4
@Repository
5
public interface PersonRepository extends MongoRepository<PersonEntity, String> {
6
7
    PersonEntity findFirstBySsn(String ssn);
8
}
