Aggregation performance

Working with Data
,
1

Hi there!
I have a certain aggregation that I’ve been struggling with, trying to improve its performance.
and it looks like the following:

db
  .getCollection("paw.readouts")
  .aggregate([
    {
      $match: {
        readoutDescriptorId: {
          $in: [
            5632, 1, 5633, 2, 3, 4, 5, 6, 8, 9,
            17, 5649, 18, 3859, 3860, 5396, 5397,
            5656, 5657, 5402, 5403, 5404, 5153,
            5154, 5414, 5415, 4910, 3888, 4912,
            5680, 3889, 5681, 5684, 5685, 5174,
            4409, 4410, 5180, 4157, 4158, 4424,
            5453, 5454, 5459, 5460, 5461, 5462,
            5468, 5469, 3944, 4968, 3945, 4969,
            5233, 5234, 5235, 4216, 4217, 4218,
            4220, 4221, 5505, 5250, 4487, 4488,
            5256, 5001, 3978, 5002, 3980, 5007,
            4240, 4241, 4761, 3998, 3999, 5279,
            5280, 5281, 5282, 4515, 5283, 5539,
            4517, 4518, 5287, 5032, 5288, 5033,
            5289, 5034, 5290, 5546, 5035, 5547,
            5036, 5037, 5038, 5294, 5039, 5555,
            4291, 4292, 5316, 4041, 5321, 4042,
            4044, 5068, 4045, 5069, 4820, 5333,
            5334, 4823, 5335, 5591, 5592, 5593,
            4826, 5594, 4827, 5595, 4828, 5596,
            4829, 5597, 4830, 5598, 4831, 5599,
            4832, 5600, 4833, 4834, 5602, 4835,
            5603, 5604, 5350, 5606, 5607, 5608,
            5098, 4587, 5099, 3822, 3823, 5360,
            5624, 4345, 5625, 4346, 5626, 5627,
          ],
        },
        archived: false,
      },
    },
    {
      $project: {
        readoutDescriptorId: 1,
        sampleId: 1,
        location: 1,
        name: 1,
        value: 1,
        alias: 1,
        species: 1,
        trackingNumber: 1,
        originLocation: 1,
        batchAlias: 1,
        replicate: 1,
        groupingId: 1,
        abpId: 1,
        biosystemId: {
          $ifNull: [
            "$superRootId",
            "$biosystemId",
          ],
        },
      },
    },
    {
      $group: {
        _id: {
          alias: "$alias",
          trackingNumber: "$trackingNumber",
          origin: "$originLocation",
          bioSystemId: "$biosystemId",
          replicate: "$replicate",
        },
        readouts: {
          $push: {
            descriptorId: "$readoutDescriptorId",
            location: "$location",
            sampleId: "$sampleId",
            readoutName: "$name",
            readoutValue: "$value",
            batchAlias: "$batchAlias",
            groupingId: "$groupingId",
            abpId: "$abpId",
          },
        },
      },
    },
    { $sort: { "_id.bioSystemId": 1 } },
    {
      $facet: {

        count: [{ $count: "count" }],
        results: [
          { $skip: 250 },
          { $limit: 250 },
        ],
        unique: [
          {
            $group: {
              _id: null,
              unique: {
                $addToSet: "$_id.bioSystemId",
              },
            },
          },
          {
            $project: {
              unique: { $size: ["$unique"] },
            },
          },
        ],
      },
    },
    {
      $project: {
        total: {
          $arrayElemAt: ["$count.count", 0],
        },
        page: "2",
        unique: {
          $arrayElemAt: ["$unique.unique", 0],
        },
        data: "$results",
      },
    },
    {
      $project: {
        data: 1,
        page: 2,
        total: { $ifNull: ["$total", "0"] },
        unique: { $ifNull: ["$unique", "0"] },
      },
    },
  ])
  .allowDiskUse()

I have an index created on readoutDescriptorId.
What else can I do to improve the performance of this aggregation?
I have to mention that this particular aggregation goes through 196082 documents. And it takes for around more than 9 sec which is quite long.
Is there any low hanging fruits that can be done to improve the performance?

2

Since you $group, your $project is mostly useless. You could use $cond on bioSystemId directly in the _id of the $group.

Your $sort after the $group cannot use an index so it is surely part of the slowness.

A $match with such a big $in list smells like snails. Are these completely arbitrary? May be they could be characterized by something else that has a smaller cardinalilty that can be expressed by another attribute.

For example, the could be ids of sensor within a region so you could match the region rather the id directly. It all depends on how you determine which id to put in the query.

You also page using $skip and $limit which is not the best way.

3

Thanks alot!!! :slight_smile: That was really helpful, actually removing the first project and moving the sorting to the top did help indeed.
What’s wrong with the limit and skip? What’s the most optimal way to page?

4

And actually I just noticed that moving the sort before the group kind of messed up this grouping I’m doing with _id, it seems that this made the grouping of id to stop working

5

I did not mean to move the $sort before the $group when I wrote

I just wanted to explain why $sort is slow. A $sort on a computed value is slow because it cannot uses an index. But you have no choice, you $sort the result of $group, so it has to be after.

6

When an aggregation takes a while you should run it with explain with "executionStats" option and see how long each stage is taking. That way you (and we) aren’t guessing which part is contributing the most to the slowness and aren’t trying to solve “the wrong problem”.

Asya

1 Like
